Reference:
http://wiki.openstreetmap.org/wiki/ Slippy_map_tilenames#Zoom_levels
Brief overview:
OSM tiles are 256x256 pixel PNG files.
Filename (URL) format is http://tile.openstreetmap.org/zoom/x/y.png
where
zoom=zoom-level-integer (from 0 to 19),
x=longitude-locator-integer (non-negative column number),
y=latitude-locator-integer (non-negative row number).
In the link above, see sample code to calculate x and y for a given zoom-level and a given latitude and longitude.
The following Maui Island map
is done with map tiles at OSM zoom level 12.
Approximate latitude,longitude of Maui:
20.7983 , -156.3319 degrees
Each OSM tile is a 256x256 PNG file.
Each zoom-level-12 tile is one image out of
2^12 x 2^12 = 4096 x 4096 = 16,777,216 images ~ 16 million images
which are used by OpenStreetMap to cover most of the Earth.
These zoom-level-12 tiles go from
x-numbers 265 to 273. (9 columns)
These zoom-level-12 tiles go from
y-numbers 1802 to 1807. (7 rows)
Total: 9 x 7 = 63 tiles
Image width: 9 x 256 = 2,304 pixels
Image height: 7 x 256 = 1,792 pixels
These tiles are fetched from the
OSM server when you (re)load this page.
So these tiles form an image using
the latest versions of the OSM tiles.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
This link provides the map in a
*SINGLE* 2304x1792 pixel PNG file
--- created from OSM tiles
as they existed on 19 Feb 2018.
After you access that link,
you can right-click on the image and
use a popup menu option such as
'Save Image As ...' to save the single
image file to your local file system.
This image file was created with a
Tcl-Tk 'tkGooies' script
in the
'MAPtools' group of 'tkGooie' scripts at the
Freedom Environment software web site.
Here is a link to an OSM (openstreetmap.org)
'slippy map'
for
Maui (Wikipedia link) --- initially at zoom-level 12 and
centered at latitude and longitude 20.7983 -156.3319,
which is near the center of the island.
